Continental 1" Minimum Bleed Quick Shut-Off Lever Valve | A-QOVM-100
Continental NH3 Products is proud to introduce our new fast fill minimum bleed riser fill valve. We increased the outlet hole by 75 percent, from 3/4" to 1" to match the inlet hole in the nurse tank valve. The minimum bleed feature allows the users to bleed the connection by loosening the coupling instead of using a bleeder valve. This is achieved by locating the seat down by the end of the coupling. This unique feature is very helpful on risers when filling nurse tanks. We use stainless steel for the bonnet, stems, poppet, and coupling nozzle for extended life.
Features:
- 75% larger outlet hole
- Up to 30 to 40 percent faster fill times
- 1" size
- Flat rubber seat makes for excellent seal
- Stainless steel bonnet, stem, poppet, and coupling nozzle
- Large aluminum hand wheel
- Rugged ductile iron body
- Knurled coupler for better grip
- Special feature allows the coupling to be removed and repaired in the field. Special tool is required.
Specifications:
- Inlet Size: 1"
- ACME Size: 1-3/4"
