Raven Precision CR7+ Field Computer Kit UT Unlock, RAM-C | 117-2295-040
The powerful lightweight display that won't break the bank.
The 117-2295-040 Raven product is a Raven CR7+ Field Computer Kit UT Unlock, RAM-C. It's a lightweight, affordable, and easy-to-use field computer with a 7-inch touchscreen and customizable in-job layouts. The kit includes UT Unlock (Universal Terminal) and RAM-C, which allows for compatibility with various implements and controllers.
The CR7+®#117-2295-040 is a 7" (17.8 cm) lightweight field computer with customizable job layouts. A simple widget concept with ISO Universal Terminal and Task Controller capabilities makes this compact unit an affordable, scalable plug-and-play system.
Raven CR7+: a Small but Mighty Display for Every Season
The CR7+ is easy to plug in and use for all operations, including planting, seeding, application, and harvest. Its lightweight build and versatile user interface adjusts for each unique implement. With seamless automatic guidance controls, CR7+ empowers you to easily run more complex equipment and operations at an affordable price point.
Key Features:
- Console
- UT Unlock
- RAM-C
- 7-inch (17.8 cm) capacitive touchscreen display.
- Simplified guidance controls. Create, swap, rename, and manage guidance lines all in one widget, making in-job adjustments easier.
- Auto field boundaries keep you organized effortlessly.
- Simple widget-based controls.
- Slingshot® ready for file transfer and remote support.
- Easily repeat your field boundary from a previous job.
- Boundary and guidance line options, including straight A-B, Pivot, Contour, and Last Pass guidance.
- Easily manage each field operation by programming all your guidance lines.
- Automatically adjusts for different implement working widths.
- Track each seed placement with crop registration data.
-
Simple, customizable user interface.
- Map-based navigation.
- Operation planning.
- Customizable data structure.
- Recommended for up to two product controls.
- Slingshot™file transfer and Remote Support.
- Slingshot™Over-the-Air Software Updates.
- Easy backup/recovery of the system.
- ISOBUS Universal Terminal.
- ISOBUS Task Controller compatible.
Specifications:
- 7" capacitive touch screen
- Integrated lightbar
- IP65 (dustand splash proof)
- iMX8+ 1.8 GHZ Quad Core Processor
- 2 CANbus channels, 3 Serial channels, One USB 2.0 Port, Gigabit Ethernet Port, Wi-Fi 802.11 b/g/n, Keyedpower start-up and shut-down, 2 separate AUX inputs for master switch
- RAM mountCE and E-markcertified
Includes:
- Monitor
- Mount
Note: to have the complete set the display cable 115-7300-194 and the 500s antenna 063-2000-006 are needed.
Faster, Brighter, and More Responsive
The CR7+ is an effective drop-in replacement for the legacy Raven CR7 display. Compared to the CR7, the CR7+ has:
- 2x the processing power.
- 4x as much memory.
- Faster boot times, averaging 20 seconds (vs. up to 60 seconds).
- A streamlined user interface with improved guidance controls.
- The same price point and functionality.
CRX+ Operating Software
The powerful, streamlined CRx+ user interface features easy set-up, fewer touches, and exclusive field planning features that help you be more efficient before and during each job. Each CRx+ feature is designed to make everyday operations more productive, including:
- Pre-planning: Use your boundary to automatically create your guidance line on each side of the field.
- Implement management automatically adjusts guidance lines based on different implement widths.
- Customize the number of guidance lines per headland, as well as the distance between the first line and boundary.
- Auto-switch between guidance lines by moving the tractor in the approximate direction of your headland.
