Product Description
Banjo 2" Manifold Inductor Assembly | MIS220AAK
The Banjo 2” Full Port Manifold Inductor Assembly is designed to be used to completely empty the inductor tank and keep it free of chemicals.
MANIFOLD INDUCTOR: ASSEMBLY 2 INCH
Features & Benefits:
- 2" full port flow by-pass.
- Easy assembly/installation with manifold connections.
- Installed after pump; suction completely empties inductor tank.
- Keeps tank free of chemicals.
- Assembly Required
Replacement Parts:
| ITEM | PART NO | DESCRIPTION | QTY |
| 1 | PLUG075 | 3/4" PIPE PLUG | 1 |
| 2 | MHV220A | 2" FULL PORT POLY VENTURI | 1 |
| 3 | M221G | 2" FULL PORT EPDM MANIFOLD GASKET WITH RIB | 10 |
| 4 | FC220 | 200 SERIES WORM SCREW CLAMP | 10 |
| 5 | M220CPG45 | 2" FULL PORT MANIFOLD 45° COUPLING | 2 |
| 6 | M220CPG6 | 2" FULL PORT MANIFOLD COUPLING | 1 |
| 7 | M220Y45 | 2" FULL PORT MANIFOLD WYE 45 | 1 |
| 8 | M220YG45 | 2" FULL PORT MANIFOLD WYE 45 GAGE PORT | 1 |
| 9 | MVS220CF | 2" STUBBY VALVE | 1 |
| 10 | M220A | 2" FULL PORT MANIFOLD FLANGE X 2" MALE COUPLER | 2 |
| 11 | MVSMT220FP | 2" FULL PORT MANIFOLD X 2" MALE NPT STUBBY VALVE | 1 |
Product Videos
Custom Field
Banjo MIS220AAK Drawing MIS220AAK Drawing
Banjo MIS220AAK Brochure MIS220AAK
Material Polyproplene
Connection Summary 2" Flange
Port Type Full
Handle Type Lever
