Flojet Electric Diaphragm Pump Miniature 1.0 GPM, 35 PSI, 12V | LFP122201D
Flojet’s new LF Series compact pumps offer up to a 1.0 GPM (3.8 LPM) flow rate and optional industry leading switch technology, proven with over 1 million cycles. The 360° quick connect swivel ports allow for complete freedom of port orientation, a cost effective solution, minimizing the need for additional components. These pumps are the ideal solution for many applications including spraying, fluid transfer, filtration, cooling, dispensing and pressure boosting.
Features:
- Flow rates up to 1.0 GPM (3.8 LPM) and operating pressures up to 40 psi (2.75 bar)
- Demand (pressure switch shut-off) or non-switch models available
- Bypass option reduces cycling, offering ideal pressures of 0.2 to 0.3 GPM for backpack spraying
- Robust material selection, suitable for handling a broad range of chemicals
- Sealed motor and pressure switch, providing years of dependable reliability
- Flojet Diaphragm pumps provide dependable run dry capabilities, extending the life of the pump
- Self priming, accommodating up to 6ft (1.8m)
- Built in thermal protector, prevents overheating to protect the pump from damage
- Quick Disconnect Ports allow for quick cleaning and easy hose replacement in seconds
- Low amp draw, ideal for battery powered applications
Specifications:
- Pump Design Reciprocating diaphragm
- Maximum Flow Rate 1.0 GPM (3.78 LPM) @ open flow
- Duty Cycle Intermittent
- Housing Material Polypropylene
- Diaphragm Santoprene®,
- Check Valve Materials Viton®
- Check Valve Spring 316 Stainless steel
- Port Type Quick disconnect - 3/8 HB Straight
- Operating Pressure 40 psi (2.75 bar) max (no pressure switch version)
- Pressure Switch Setting 40 psi (2.75 bar) off / 25 psi (1.7 bar) on
- Self Priming Up to 6ft (1.8m)
- Liquid Temperature 110°F (43°C) maximum
- Motor Type Permanent magnet motor
- Motor Voltage 12 VDC, 24 VDC, 115 VAC
- Current for 12 VDC 2.5 amps @ 25 psi (1.7 bar)
- Certifications CSA, CE*, NSF*, UL*
- Weight 1.25lbs (0.5kg)
Applications:
- General Industrial
- Chemical wash down
- Evaporative Cooling Systems
- Fluid Transfer
- RO Filtration
- Food & Beverage
- Food Processing
- Water Dispense
- Agricultural
- Fogging / Misting
- ATV & Backpack Sprayers
- Automotive
- De-watering
