Product Description
Granit KX7 Standard Threshing Concave Kit Small Grain, New Holland CR Series | 716-090
KX7 Concave kit for New Holland CR Series combines with dual rotors (Fits CR8.90, CR9.80, CR9.90, CR10.90, CR980, CR8080, CR890, CR9080, CR9090, CR970, CR9070).
This kit is ideal for use in small grains such as wheat, oats, rye, barley, and other cereals which provides upgraded performance as compared to OEM concaves; especially when harvesting in tough conditions.
The concave kit comes disassembled such that installation begins with the black frame assemblies into the machine. Once the black frames are installed each of the boxes are to be bolted in. Instructions provided with the kit.
Concave kit consists of the following components:
- 1x 716-085 frame assemblies (2 pieces makeup this sub-kit number)
- 2x BB8-X12 (RH,ADJ FRAME Max Thresh positions 1-2)
- 2x BB8-X11 (RH,MAIN FRAME Max-Thresh positions 1-2)
- 1x BB8-R12 (RH, ADJ FRAME Max-Round position 3)
- 1x BB8-R11 (RH, MAIN FRAME Max-Round position 3)
- 2x BB8-X22 (LH, ADJ FRAME Max-Thresh positions 1-2)
- 2x BB8-X21 (LH, MAIN FRAME Max-Thresh positions 1-2)
- 1x BB8-R22 (LH, ADJ FRAME Max-Round position 3)
- 1x BB8-R21 (LH, MAIN FRAME Max-Round position 3)
To fit:
- CR8.90
- CR9.80
- CR9.90
- CR10.90
- CR980
- CR8080
- CR890
- CR9080
- CR9090
- CR970
- CR9070
Replaces:
- 47444229
- 47449709
- 47449704
- 47449699
