Pioneer John Deere Female Tip Quick Coupling | 4056-4
Pioneer has been “The Farmer’s Choice” for more than 70 years, and it is the world leader in quick coupling products for the agricultural industry.
Pioneer agricultural products provide the most reliable and exacting aftermarket OEM interchanges in the industry. Couplers and nipples connect with specific OEM brand quick coupling styles. Agricultural male tip and female body interchange styles include: Allis Chalmers, J I Case, Ford, John Deere, International Harvester (CNH), and Massey - Ferguson.
Female Tip. Connects with John Deere AR30210 and Pioneer 5060-4 male tips. Interchange for John Deere AR47331. Has a single acting sleeve and will connect only after trapped pressure has been released.
Specifications:
- Product Description: John Deere Female Tip
- Pioneer Part Number: 4056-4
- Port End: 1/2"-14 NPTF
- Rated Pressure(psi): 3000
- Body Size: 1/2 inch
- Coupling Half: Coupler - Female Socket
- Competitor Part Number: John Deere (old style) coupler AR47331
- Function: Connects with John Deere AR30210 and Pioneer 5060-4 male tips
Technical Characteristics:
- Size: 1/2”
- Material: Steel
- Interchange Styles: Allis Chalmers, J I Case, Ford, John Deere, International Harvester (CNH), and Massey - Ferguson
Markets:
- Agriculture
- Aftermarket replacement, maintenance and repair
Features/Benefits:
- Wide range of coupling styles to interchange with major farm equipment brand implement male tips and female coupler bodies
- Male tips have hardened locking ball grooves to resist wear and provide protection from Brinelling
- Positive valve stop prevents flow checking for smooth performance
Applications:
- Tractor attachments / implements
- Agricultural farm equipment
- Hydraulic Loaders
- Ag/mobile attachments
O.E.M Part Number: N.A.
