ShurFlo 12V Mini-Bulk Pump | SF-1100
The stand-alone chemical transfer pump SF-1100 includes a 12 VDC motor, 20' cable with alligator clips and an inline fuse. The pump does not include any tank couplings, ball valves or mounting devices. The highly efficient design utilizes a 3" diameter permanent magnet motor, more
performance and less weight, without more cost. The pump delivers increased flow with viscous micro-encapsulated or suspended chemicals. This high flow rate while pumping viscous chemicals, in combination with free-flowing return loop, provides substantially increased turnover rate on
recirculation models. The proprietary designed co-molded diaphragm molecularly bonds the pump piston to the diaphragm in the molding process. The result is an inherently leak-proof diaphragm capable of years of trouble free service. While designed and tested to provide high performance and years of durability, the SF-1100 is field serviceable with hand tools. It is also capable of priming up to 12'.
Features:
- Specialized EPDM elastics or Viton® option
- 12 volt DC or 110 volt AC motor option
- 20 foot (6 m) cord with alligator clips and in-line fuse (DC version), 6 foot (1.8) cord (AC version)
- Weather protected on/off switch
- Internal bypass to protect the pump at shut-off
- 2" MNPT inlet, 1" FNPT outlet
- Capable of priming up to 12 feet (3.7 m)
- Max Viscosity: 600-880 Centipoise
