Continental NH3 Tank Combination Valve 1-1/4" MPT X 1-1/4" FPT | B-1206-F (Formally A-1206-F)
Withdrawal valves are available in a wide variety of connections, from 1-1/4" and 1-1/2" MPT tank connections with 1", 1-1/4" or 1-1/2" FPT outlets as well as 2-1/4" ACME male outlets. A 1/4" FPT outlet port is also provided for the installation of a desired accessory. This particular valve can be used for vapor, filler or liquid withdrawal.
Features:
- Tank Connection Size: 1- 1/4" MPT
- Outlet Size: 1-1/4" FPT
- Excess Flow Check Rating: 42 GPM
- Side Port & Feature: A-400 Relief
- Stainless steel stem - precision ground and polished.
- Spring loaded "teflon" stem packing - positive seal with pressure tested at 400 psi.
- Optional double coated, zinc plated and painted for extra protection.
- Excess flow check assembly of all valves individually inspected and checked after assembly to assure accurate and dependable operation.
- Spring loaded packing for a free spinning hand wheel.
