Pioneer 4000 Series Female Quick Coupler | 4050-4
The 4000 Series brings to the industry a proven design for use on agricultural machinery and other rugged applications.
4000 Series Couplers (hydraulic) 3000 psi, connect with 4000 Series Nipples and 1/2"" 8010 Series Nipples (ISO 5675, Pioneer male tips).
Parker's 4000 Series are double shut-off quick couplings with poppet or ball valve options. Couplers have a manual sleeve. Push-pull breakaway sleeve is only available on 1/4" body size with 9/16 - 18 ORB thread, part number 4050P-T6.
4000 Series Nipples (hydraulic) 3000 psi, connect with 4000 Series Couplers and 4200 Series Couplers.
Features:
- Accepts ISO 5675 universal tips
- Basic operation where coupler sleeve is manually retracted to allow connection with male tip
- Critical parts are induction hardened
- Ball and poppet valve options
- Protective zinc plating with clear trivalent chromate finish
- Proven design for rugged applications
- 1/2" size globally connects with Pioneer universal male tips (nipples) complying to ISO 5675
Specifications:
- Body Size: 1/2"
- Coupler Part Number: 4050-4
- Port End: 1/2-14 NPTF
- Valve Type: Ball
- Length: 2.60"
- Largest Diameter: 1.50"
- Wrench Flats: 1.06 inch
- Weight(lbs): 0.58
- Complete Coupling Part Number: 4000-4
- Coupling Half: Female Coupler
- Specifications Met: ISO 5675
- Maximum Operating Pressure: 3000 psi
- Product Type: Manual sleeve
- Application: Hydraulics, General Purpose
- Valve Type: Ball
- Maximum Operating Temperature: 250 °F
- Minimum Operating Temperature: -40 °F
- Connection Thread Size (inch): 1/2 - 14
- Body Material: Steel
- Flow Rate: 12 gal/min
- Seal Material: Nitrile
- Plating Type: Zinc with Clear Trivalent Chromate
Applications include:
- Hydraulic Loaders
- Add-on hydraulic circuits
- Hydraulic tools
- Snowplow attachments
- Tractors and agricultural equipment
Technical Characteristics:
- Sizes: 1/4” – 1”
- Material: Steel
- Port Ends: Female NPTF, Female ORB, Male ORB, Female BSPP
- Seal Options: Nitrile, EPR, Fluorocarbon, Neoprene
Markets:
- Agriculture
- Mobile Equipment
- Construction
- Snow removal
- Industrial
